| Location in Parts Diagram | Part # | Description | Quantity Used |
|---|
| 1 | 194938 | COMPLETE TUNNEL | 1 |
| 2 | 68886300 | COMPLETE R.H. LATERAL HALF FLOOR -Not for GD- | 1 |
| 2 | 69413211 | COMPLETE R.H. LATERAL HALF FLOOR -Valid for GD- | 1 |
| 3 | 68886400 | COMPLETE L.H. LATERAL HALF FLOOR -Not for GD- | 1 |
| 3 | 69413311 | COMPLETE L.H. LATERAL HALF FLOOR -Valid for GD- | 1 |
| 4 | 207193 | R.H. FRONT CROSS MEMBER | 1 |
| 5 | 205203 | R.H. REAR CROSS MEMBER | 1 |
| 6 | 207192 | L.H. FRONT CROSS MEMBER | 1 |
| 7 | 205202 | L.H. REAR CROSS MEMBER | 1 |
| 8 | 68886500 | R.H. LATERAL REAR CROSSMEMBAR | 1 |
| 9 | 68886600 | L.H. LATERAL REAR CROSSMEMBAR | 1 |
| 10 | 166232 | R.H. REINFORCEMENT FRAME | 1 |
| 11 | 166132 | L.H. REINFORCEMENT FRAME | 1 |
| 12 | 201435 | R.H. CROSSMEMBER | 1 |
| 13 | 70000950 | INSERTS KIT FOR REPAIR | 1 |
| 14 | 201434 | L.H. CROSSMEMBER | 1 |
| 15 | 202560 | REAR SHIELD | 1 |
| 16 | 64811011 | R.H. REAR FIXING FRAME | 1 |
| 17 | 64811111 | L.H. REAR FIXING FRAME | 1 |
| 18 | 65153400 | R.H. FRONT SIDE MOLDING | 1 |
| 19 | 65153511 | L.H. FRONT SIDE MOLDING | 1 |
| 20 | 65998100 | R.H. REAR SIDE MOLDING | 1 |
| 21 | 65998200 | L.H. REAR SIDE MOLDING | 1 |
| 22 | 64804300 | R.H. REWINDER FIXING REINFORCEMENT | 1 |
| 23 | 64804400 | L.H. REWINDER FIXING REINFORCEMENT | 1 |
| 24 | 64803500 | R.H. LATERAL SEAL | 1 |
| 25 | 64803600 | L.H. LATERAL SEAL | 1 |
| 26 | 196081 | L.H. REINFORCEMENT | 1 |
| 27 | 196082 | R.H. REINFORCEMENT | 1 |
| 28 | 14642891 | POP RIVET L. 14 mm | |
| 29 | 65133800 | RIVET L. 6,4 mm | |
| 30 | 15624311 | ESAGONAL RIVET M5 | |
| 30 | 15624411 | ESAGONAL RIVET M6 | |
| 30 | 15624511 | ESAGONAL RIVET M8 | |
| 30 | 15180411 | BLIND ESAGONAL RIVET | |
| 30 | 15624211 | ESAGONAL RIVET M4 | |
| 31 | 65151200 | RIVET M6 | |
| 32 | 166101 | RIVET M4 | |
| 32 | 65135000 | RIVET M8 | |
| 32 | 65930400 | RIVET M6 | |
| 32 | 65319800 | RIVET M8 BLIND | |
| 32 | 60853400 | RIVET M10 BLIND | |
| 33 | 65065400 | STUD ESAGONAL HEAD M6 | |
| 34 | 13836771 | SCREW | |
| 35 | 66464800 | R.H. PANEL UPPER FRAME | 1 |
| 36 | 66464900 | L.H. PANEL UPPER FRAME | 1 |
| 37 | 65386100 | R.H. SUPPORT CENTRAL OVERLAP | 1 |
| 38 | 65386200 | L.H. SUPPORT CENTRAL OVERLAP | 1 |
| 39 | 182624 | R.H. FUEL TANK PROTECTION PLATE -Not as spare part now- -Replaced by 219918- | 1 |
| 39 | 219918 | R.H. FUEL TANK PROTECTION PLATE | 1 |
| 40 | 182623 | L.H. FUEL TANK PROTECTION PLATE -Not as spare part now- -Replaced by 219843- | 1 |
| 40 | 219843 | L.H. FUEL TANK PROTECTION PLATE | 1 |
| 41 | 65903600 | R.H. STRIKER REINFORCEMENT | 1 |
| 42 | 65903700 | L.H. STRIKER REINFORCEMENT | 1 |
| 43 | 202682 | R.H. REAR REINFORCEMENT | 1 |
| 44 | 202681 | L.H. REAR REINFORCEMENT | 1 |
| 45 | 207194 | FRONT CROSS MEMBER FOR BATTERY BIN -Not for GD- | 1 |
| 45 | 208941 | FRONT CROSS MEMBER FOR BATTERY BIN -Valid for GD- | 1 |
| 46 | 207195 | FRONT CROSS MEMBER FOR ACCELERATOR PEDAL CASTING FIXING -Not for GD- | 1 |
| 46 | 208940 | FRONT CROSS MEMBER FOR ACCELERATOR PEDAL CASTING FIXING -Valid for GD- | 1 |
| 47 | 207196 | L.H. FRONT REINFORCEMENT | 1 |
| 48 | 208939 | R.H. FRONT REINFORCEMENT -Valid for GD- | 1 |
| 48 | 207197 | R.H. FRONT REINFORCEMENT -Not for GD- | 1 |
| 49 | 207198 | L.H. REAR REINFORCEMENT -Not as spare part now- -Replaced by 207198- | 1 |
| 49 | 207198 | L.H. REAR REINFORCEMENT | 1 |
| 50 | 207199 | R.H. REAR REINFORCEMENT -Not as spare part now- -Replaced by 207199- | 1 |
| 50 | 207199 | R.H. REAR REINFORCEMENT | 1 |
| 51 | 181981 | CORE FOR REPAIR | |
| 52 | 181980 | UPPER INNER CORE | |
| 53 | 181979 | LOWER INNER CORE | |
| 14 | 65520000 | FRONT FIXING BRACKET | 4 |
| 15 | 10902024 | SCREW | 8 |
| 16 | 12640677 | WASHER | 8 |
| 17 | 140594 | REAR SIDE-MARKER LAMP -Valid for USA and CDN | 2 |
| 17 | 147563 | FRONT SIDE-MARKER LAMP -Valid for USA and CDN | 2 |
| 18 | 65164700 | HEADLIGHTS WASHER PUMP -Valid for cars with headlights washer | 1 |
| 19 | 65511700 | GASKET -Valid for cars with headlights washer | 1 |
| 20 | 65363000 | HEADLIGHTS WASHER PIPE ASSEMBLY -Valid for cars with headlights washer | 1 |
| 21 | 65380000 | HEADLIGHTS WASHER FIXED BODY -Valid for cars with headlights washer | 2 |
| 22 | 65380100 | L.H. HEADLIGHTS WASHER MOBILE BODY -Valid for cars with headlights washer | 1 |
| 22 | 65667200 | R.H. HEADLIGHTS WASHER MOBILE BODY -Valid for cars with headlights washer | 1 |
| 23 | 15517201 | SCREW -Valid for cars with headlights washer | 6 |
| 24 | 65896600 | R.H. SUPPORT -Valid for cars with headlights washer | 1 |
| 24 | 65896700 | L.H. SUPPORT -Valid for cars with headlights washer | 1 |
| 25 | 65896400 | R.H. PLUG -Valid for cars with headlights washer | 1 |
| 25 | 65896500 | L.H. PLUG -Valid for cars with headlights washer | 1 |
| 26 | 10441590 | BRACKET -Valid for cars with headlights washer | 4 |
| 27 | 14296191 | RIVET -Valid for cars with headlights washer | 4 |
| 28 | 65161700 | L. H. FRONT SIDE LIGHT SUPPORT | 1 |
| 28 | 65161500 | R. H. FRONT SIDE LIGHT SUPPORT | 1 |
| 29 | 10902424 | SCREW | 2 |
| 30 | 116413 | WASHER | 2 |
| 31 | 63234200 | SCREW | 2 |
| 32 | 12646801 | WASHER | 2 |
| 33 | 185378 | CLIP | 3 |
| 34 | 183672 | BULB -For gas lamps | 2 |
| 35 | 65705600 | L.H. BRACKET -For gas lamps | 1 |
| 35 | 65705500 | R.H. BRACKET -For gas lamps | 1 |
| 36 | 65705400 | BRACKET -For gas lamps | 2 |
| 37 | 185554 | FRONT LIGHT CONTROL STATION -For gas lamps | 2 |
| 38 | 155751 | CLIP -Valid for USA and CDN | 4 |
| 39 | 14084111 | NUT -Valid for USA and CDN | 8 |
| 40 | 12638124 | WASHER -Valid for USA and CDN | 8 |
| 41 | 66120200 | INSULATION | 1 |
| 42 | 14190190 | NUT WITH CAGE | 2 |
| 43 | 64529600 | SPACER | 8 |
| 4 | 66325702 | Description not available | |
| 4 | 67259102 | Description not available | |
| 4 | 66325725 | Description not available | |
| 4 | 67259127 | Description not available | |
