Click on part number below to order. If unable to click on part number please fill out and submit Parts Request Form below to order.
| Location in Parts Diagram | Part # | Description | Quantity Used |
|---|
| 1 | 67771410 | REAR BUMPER -Plastic rear covering- -Not for USA and CDN- | 1 |
| 1 | 69452510 | REAR BUMPER -With moulding- -Valid for USA and CDN- -Parking sensors- -Optional- | 1 |
| 1 | 68590510 | REAR BUMPER -With moulding- -Valid for USA and CDN- -Optional- | 1 |
| 1 | 69451510 | REAR BUMPER -With moulding- -Not for USA and CDN- -Parking sensors- -Optional- | 1 |
| 1 | 68507810 | REAR BUMPER -With moulding- -Not for USA and CDN- -Optional- | 1 |
| 1 | 69451910 | REAR BUMPER -Plastic rear covering- -Valid for USA and CDN- -Parking sensors- -Optional- | 1 |
| 1 | 68590210 | REAR BUMPER -Plastic rear covering- -Valid for USA and CDN- | 1 |
| 1 | 69451010 | REAR BUMPER -Plastic rear covering- -Not for USA and CDN- -Parking sensors- -Optional- | 1 |
| 2 | 67772100 | ER UPHOLSTERY FOR REAR BUMPER -Grey- | 1 |
| 2 | 69140500 | ER UPHOLSTERY FOR REAR BUMPER -Black- | 1 |
| 3 | 68854700 | R.H. BRACKET | 1 |
| 4 | 68854800 | L.H. BRACKET | 1 |
| 5 | 67772700 | CENTER GRILLE | 1 |
| 6 | 68099100 | LOWER GRILL | 1 |
| 7 | 68099000 | UPPER GRILL | 1 |
| 8 | 68164700 | R.H. PROFILE FOR TAILS | 1 |
| 9 | 68164800 | L.H. PROFILE FOR TAILS | 1 |
| 10 | 68148300 | BUMPER LATERAL FIXING BRACKET | 2 |
| 11 | 62126600 | PLATE | 2 |
| 12 | 104030 | NUT | 4 |
| 13 | 62128200 | EXTERNAL SMALL BLOCK | 2 |
| 14 | 62128300 | INTERNAL SMALL BLOCK | 2 |
| 15 | 12646801 | WASHER | 4 |
| 16 | 104114 | NUT | 2 |
| 17 | 12601474 | WASHER | 2 |
| 18 | 11307021 | SCREW | 2 |
| 19 | 186180 | NUMBER PLATE LIGHT | 2 |
| 20 | 10857790 | BULB | 1 |
| 21 | 15901570 | SCREW | 4 |
| 22 | 182985 | CABLES FOR NUMBER PLATE LIGHTS | 1 |
| 23 | 10399280 | CABLE GROMMET | 2 |
| 24 | 68355700 | SPACER -Not as spare part- -Replaced by 69742100- | 4 |
| 24 | 69047600 | SPACER -Possible fitting- -Not as spare part- -Replaced by 69742100- | 4 |
| 24 | 69742100 | SPACER | 2 |
| 24 | 69047700 | SPACER -Possible fitting- | 8 |
| 25 | 12164710 | NUT -Not as spare part now- -Replaced by 104114- | 8 |
| 25 | 104114 | NUT | 8 |
| 26 | 60032109 | CAVALLINO RAMPANTE | 1 |
| 27 | 65886300 | REAR PLATE FRAME -Valid for USA and CDN- | 1 |
| 27 | 65887600 | REAR PLATE FRAME -Valid for J- | 1 |
| 27 | 69277100 | REAR PLATE FRAME -Valid for China- | 1 |
| 28 | 67091000 | CATADIOPTRIC | 2 |
| 29 | 12578011 | NUT | 4 |
| 30 | 13577701 | WASHER | 4 |
| 31 | 62797600 | SCREW -Black- | 6 |
| 31 | 62797600 | SCREW -Grey- -Not as spare part- -Replaced by 62797600- | 6 |
| 32 | 14042177 | NUT | 2 |
| 33 | 16084370 | SCREW -Valid for USA and CDN- | 4 |
| 34 | 14201980 | BLOCK -Valid for USA and CDN- | 2 |
| 35 | 14295696 | RIVET -Valid for USA and CDN- | 4 |
| 36 | 12644301 | WASHER | 8 |
| 37 | 214561 | PARKING SENSOR -Parking sensors- -Optional- | 4 |
| 38 | 223516 | GASKET -Parking sensors- -Optional- | 4 |
| 39 | 69318100 | SLEEVE -Parking sensors- -Optional- | 4 |
| 40 | 221270 | BUMPER CABLE WITH PARKING SENSOR -Parking sensors- -Optional- | 1 |
| 41 | 69329100 | PLUG -Parking sensors- -Optional- | 2 |
| 42 | 69449400 | GASKET -Parking sensors- -Optional- | 2 |
| 43 | 10444624 | SCREW -Parking sensors- -Optional- | 12 |
| 44 | 13579004 | WASHER -Parking sensors- -Optional- | 12 |
| 14 | 65520000 | FRONT FIXING BRACKET | 4 |
| 15 | 10902024 | SCREW | 8 |
| 16 | 12640677 | WASHER | 8 |
| 17 | 140594 | REAR SIDE-MARKER LAMP -Valid for USA and CDN | 2 |
| 17 | 147563 | FRONT SIDE-MARKER LAMP -Valid for USA and CDN | 2 |
| 18 | 65164700 | HEADLIGHTS WASHER PUMP -Valid for cars with headlights washer | 1 |
| 19 | 65511700 | GASKET -Valid for cars with headlights washer | 1 |
| 20 | 65363000 | HEADLIGHTS WASHER PIPE ASSEMBLY -Valid for cars with headlights washer | 1 |
| 21 | 65380000 | HEADLIGHTS WASHER FIXED BODY -Valid for cars with headlights washer | 2 |
| 22 | 65380100 | L.H. HEADLIGHTS WASHER MOBILE BODY -Valid for cars with headlights washer | 1 |
| 22 | 65667200 | R.H. HEADLIGHTS WASHER MOBILE BODY -Valid for cars with headlights washer | 1 |
| 23 | 15517201 | SCREW -Valid for cars with headlights washer | 6 |
| 24 | 65896600 | R.H. SUPPORT -Valid for cars with headlights washer | 1 |
| 24 | 65896700 | L.H. SUPPORT -Valid for cars with headlights washer | 1 |
| 25 | 65896400 | R.H. PLUG -Valid for cars with headlights washer | 1 |
| 25 | 65896500 | L.H. PLUG -Valid for cars with headlights washer | 1 |
| 26 | 10441590 | BRACKET -Valid for cars with headlights washer | 4 |
| 27 | 14296191 | RIVET -Valid for cars with headlights washer | 4 |
| 28 | 65161700 | L. H. FRONT SIDE LIGHT SUPPORT | 1 |
| 28 | 65161500 | R. H. FRONT SIDE LIGHT SUPPORT | 1 |
| 29 | 10902424 | SCREW | 2 |
| 30 | 116413 | WASHER | 2 |
| 31 | 63234200 | SCREW | 2 |
| 32 | 12646801 | WASHER | 2 |
| 33 | 185378 | CLIP | 3 |
| 34 | 183672 | BULB -For gas lamps | 2 |
| 35 | 65705600 | L.H. BRACKET -For gas lamps | 1 |
| 35 | 65705500 | R.H. BRACKET -For gas lamps | 1 |
| 36 | 65705400 | BRACKET -For gas lamps | 2 |
| 37 | 185554 | FRONT LIGHT CONTROL STATION -For gas lamps | 2 |
| 38 | 155751 | CLIP -Valid for USA and CDN | 4 |
| 39 | 14084111 | NUT -Valid for USA and CDN | 8 |
| 40 | 12638124 | WASHER -Valid for USA and CDN | 8 |
| 41 | 66120200 | INSULATION | 1 |
| 42 | 14190190 | NUT WITH CAGE | 2 |
| 43 | 64529600 | SPACER | 8 |
| 4 | 66325702 | Description not available | |
| 4 | 67259102 | Description not available | |
| 4 | 66325725 | Description not available | |
| 4 | 67259127 | Description not available | |
